Author:
Michael Kadoch
|
MRI Cine SSFP |
MRI T1-weighted precontrast |
MRI T2-weighted |
MRI T1-weighted postcontrast |
NECT |
CECT |
US |
Radiograph |
Gross pathology |
Histology |
Additional comments |
Benign: |
|
|
|
|
|
|
|
|
|
|
|
Myxoma |
Low signal.
|
Isointense, heterogeneous. May see point of attachment to atrium.
|
Hyperintense, heterogeneous.
|
Low to high enhancement. Heterogeneous foci of enhancement.
|
Ovoid hypoattenuating atrial mass. May see foci of internal calcification.
|
Heterogeneous enhancement.
|
Lobular, papillary, heterogeneous, echogenic atrial mass.
|
May see a prominent left atrial appendage or a dense ovoid intracardiac calcification. Excised specimens may also demonstrate dense calcifications.
|
Firm multilobular mass with a variegated surface. May see calcification or hemorrhage.
|
Myxomatous stroma containing abundant hemosiderin. May contain calcification.
|
Interauricular septum. Females. 30-60 years old. Mean size 5.7 cm.
|
|
|
|
|
|
|
|
|
|
|
|
|
Rhabdomyoma |
Noncontractile areas. (No image available.)
|
Iso- or hyperintense. Diffuse heterogeneous nodular thickening of the left ventricular myocardium and interventricular septum.
|
Slightly hyperintense. (No image available.)
|
Strong. (No image available.)
|
|
|
|
|
Multiple firm white nodules distributed throughout the left ventricular myocardium.
|
Vacuolated cells with cytoplasmic streaming artifact that results in "spider cells."
|
Left ventricle. Most common primary tumor of the heart in infants and children. Mean size 4 cm. Multiplicity.
|
|
|
|
|
|
|
|
|
|
|
|
|
Lipoma |
Hyperintense.
|
Hyperintense. Smooth, round, intracavitary mass with signal intensity characteristic of fat.
|
Hyperintense.
|
Nonenhancing.
|
Hypoattenuating. Fat density. (No image available.)
|
Hypoattenuating. Fat density. Nonenhancing.
|
Echogenic intracavitary mass.
|
|
Well-circumscribed, spherical, yellow mass.
|
|
Any location. Adults. Suppression with fat saturation techniques.
|
|
|
|
|
|
|
|
|
|
|
|
|
Fibroma |
Iso- or hyperintense.
|
Iso- or hyperintense. Large homogeneous mural mass.
|
Hypointense.
|
Variable. (No image available.)
|
|
|
|
|
Large mural mass.
|
Largely acellular with dense collagen bundles.
|
Left ventricle. Children. Mean size 5 cm. Calcification.
|
|
|
|
|
|
|
|
|
|
|
|
|
Papillary Fibroelastoma |
Turbulent flow.
|
Isointense.
|
Hypointense.
|
Not published. Here seen as a nonenhancing mass involving the mitral valve.
|
May not be seen. Here are 2 cases, one involving the aortic valve and the other involving the mitral valve.
|
Nonenhancing. Here seen are 2 cases, one involving the aortic valve and the other involving the mitral valve.
|
Echogenic mass.
|
|
Gelatinous, multilobular, papillary mass.
|
|
Left-sided valves (most commonly the aortic valve, followed by the mitral valve). Mean age is 60 years old. Mean size 1 cm. Benign endocardial papillomas.
|
|
|
|
|
|
|
|
|
|
|
|
|
Hemangioma |
Intracavitary ventricular mass.
|
Isointense. Intracavitary ventricular mass.
|
Hyperintense, heterogeneous.
|
Strong, heterogeneous.
|
|
|
Vascular mass. (No image available.) |
|
Tan, bosselated mass.
|
Characteristic dilated vascular channels interspersed among myocardial cells. Scattered fat cells within the interstitium.
|
Any location. Variable population. Small calcifications.
|
|
|
|
|
|
|
|
|
|
|
|
|
Paraganglioma |
|
Iso- or hypointense. Round, lobular mass.
|
Hyperintense. (No image available.)
|
Strong. (No image available.)
|
|
|
|
|
|
Classic nesting appearance of the paraganglial cells.
|
Left atrium. 30-40 years old. Paraneoplastic catecholamine syndrome.
|
|
|
|
|
|
|
|
|
|
|
|
|
Teratoma |
Variable. (No image available.)
|
Large, heterogeneous, lobular, multicystic pericardial mass.
|
|
|
|
|
|
May see an enlarged cardiac silhouette with a tooth that projects over the heart.
|
Firm, white lobular, multilocular cystic mass.
|
Neuroretinal (ectodermal) and glandular (endodermal) structures.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bronchogenic Cyst |
Hyperintense.
|
Hypointense.
|
Hyperintense.
|
None.
|
|
|
|
|
|
|
Interauricular septum. Adults. Differential diagnosis includes hydatid cyst.
|
|
|
|
|
|
|
|
|
|
|
|
|
Malignant: |
|
|
|
|
|
|
|
|
|
|
|
Angiosarcoma |
Hypointense foci. (No image available.)
|
Isointense with hyperintense areas. (No image available.)
|
Iso- to hyperintense. Heterogeneous. Nodular invasive tumor.
|
Strong. (No image available.)
|
|
Large, nodular, homogeneous, invasive soft-tissue mass.
|
|
|
|
Irregular anastamosing vascular channels lined by atypical endothelial cells.
|
Right atrium. Males. 30-50 years old. Possible pericardial origin. Hemorrhage.
|
|
|
|
|
|
|
|
|
|
|
|
|
Unclassified sarcoma |
|
Isointense. Large invasive mass.
|
Isointense. (No image available.)
|
Nonspecific. (No image available.)
|
Intracavitary soft tissue mass arising from the interventricular septum.
|
Intracavitary soft tissue mass arising from the interventricular septum.
|
|
|
Nodular mass invading the left atrial wall and mitral valve.
|
|
Left atrium. Variable population. Infiltrative or mass-like appearance. Possible pericardial origin.
|
|
|
|
|
|
|
|
|
|
|
|
|
Rhabdomyosarcoma |
|
Usually isointense. Here seen as a mass arising from the interatrial septum.
|
Isointense, heterogeneous. Here seen arising from the myocardial wall of the right ventricle.
|
Central nonenhancing areas. (No image available.)
|
|
No predilection for a specific chamber. Hypodense mass arising anywhere in the myocardium, including from the valves (here arising from the left atrium).
|
|
|
Various textures. Often with areas of central necrosis or cystic degeneration.
|
Two main forms seen on analysis: embryonal neoplasms (children and young adults) and adult rhabdomyosarcoma (less common in the heart). (No image available.)
|
Any location. Most common cardiac malignancy in infants and children. Necrosis. (No image available.)
|
|
|
|
|
|
|
|
|
|
|
|
|
Primary Cardiac Lymphoma |
Hypo- or isointense.
|
Hypo- or isointense.
|
Hyperintense.
|
Variable. Here demonstrating circumferential enhancement.
|
|
|
|
Superior vena cavogram may show a large intraluminal tumor that obstructs the vena cava.
|
Firm, white, multinodular tumor with plaquelike infiltration and obstruction of the superior vena cava.
|
Dark blue round lymphoma cells surrounding and infiltrating residual myocytes.
|
Right atrium. Immunocompromised patients. No necrosis. Possible pericardial origin. Rarely intracavitary.
|
|
|
|
|
|
|
|
|
|
|
|
|
Osteosarcoma |
|
Hyperintense. (No image available.)
|
Hyperintense. (No image available.)
|
Nonspecific. (No image available.)
|
May see dense calcifications associated with a hypodense mass, usually in the left atrium. Calcifications may often be mistaken for benign, dystrophic calcifications.
|
Contrast administration helps outline the extent of the tumor, here seen in the left ventricle.
|
|
|
Pericardial rind and extensive mural involvement. Foci of calcification are also seen.
|
|
Most often arises in the left atrium, versus metastatic osteosarcoma which often arises in the right atrium. Variable population. Calcifications.
|
|
|
|
|
|
|
|
|
|
|
|
|
Leiomyosarcoma |
|
Isointense. Aggressive mass.
|
Hyperintense. (No image available.)
|
Nonspecific. (No image available.)
|
|
|
|
Nonspecific. Here seen with left atrial enlargement, pulmonary vascular redistribution, and pulmonary interstitial edema with Kerley B lines.
|
|
|
Left atrium. Variable population. Pulmonary veins and mitral valve involvement.
|
|
|
|
|
|
|
|
|
|
|
|
|
Metastasis |
Variable.
|
Variable. Here seen as an isointense right atrial mass.
|
Variable. Here seen as a hyperintense right atrial mass.
|
Variable. Here seen as an enhancing right atrial mass.
|
|
Extremely variable. Here seen are two separate cases of metastatic disease to the heart.
|
|
|
|
|
More common than primary cardiac tumors. Common metastases to the heart and pericardium: lung, lymphoma/leukemia, breast, melanoma, esophageal. Can spread by retrograde lymphatic flow, hematogenously, direct extension, or transvenous extension. RA/RV more commonly involved than LA/LV.
|
|
|
|
|
|
|
|
|
|
|
|
|
Tumor-Like: |
|
|
|
|
|
|
|
|
|
|
|
Thrombus |
Hypointense.
|
Hypointense, heterogeneous mass.
|
Hypointense. (No image available.)
|
Typically does not enhance.
|
|
Soft tissue mass. Usually homogeneous in attenuation. May calcify. Here seen are two separate cases of LV apex thrombus.
|
Laminated appearance, irregular or lobulated borders, microcavitations, and absence of a pedicle. (No image available.)
|
|
|
|
May see atrial or ventricular dilatation. History of indwelling catheter, atrial fibrillation, valvular disease, or prior myocardial infarction with aneurysm formation.
|
|
|
|
|
|
|
|
|
|
|
|
|
Valvular vegetations |
Hypointense.
|
|
|
|
May see sequelae of the infection. For example, multiple cavitary lung lesions as seen here.
|
Pedunculated vegetation may be seen on the valve (here along the mitral valve). May also see perivalvular abscess or associated pseudoaneurysm.
|
Hyperechoic, irregular mass usually on the low pressure side of the valve leaflet. See oscillation during the cardiac cycle.
|
May see cavitary lung lesions. (No image available.)
|
Vegetation seen adherent to the valve (posterior mitral leaflet seen here).
|
|
Predisposing factors for endocarditis include intravenous drug use, poor dental hygiene, long-term hemodialysis, diabetes mellitus, mitral valve prolapse syndrome, and prosthetic valves.
|
|
|
|
|
|
|
|
|
|
|
|
|
Lipomatous hypertrophy |
Hyperintense.
|
Hyperintense.
|
Hyperintense.
|
Nonenhancing.
|
|
Wedge-shaped fatty thickening of the interatrial septum. Fatty tissue may extend into the right atrium.
|
|
|
|
|
Interatrial septum. Nonneoplastic accumulation of fat cells. Associated with advancing age and obesity. Can result in supraventricular arrhythmias.
|
|
|
|
|
|
|
|
|
|
|
|
|
